Basic product information:

产品参数

质粒类型：亚细胞器定位载体

启动子：CMV

载体大小：4989 bp

载体抗性：Kanamycin

筛选标记：Neomycin (select with G418)

报告基因：iRFP713

载体介绍

参考文献：

Near-infrared fluorescent proteins for multicolor in vivo imaging. Shcherbakova DM, Verkhusha VV. Nat Methods. 2013 Jun 16. doi: 10.1038/nmeth.2521. 10.1038/nmeth.2521 PubMed 23770755

Gene/Insert name：iRFP713

Species：Rhodopseudomonas palustris

Insert Size (bp)：951

Total vector size (bp)：4989

Mutation：T2A, S13L, A92T, V104T, V114I, E161K, Y193K, F198Y, D202T, I203V, Y258F, A283V, K288T, N290Y relative to RpBphP2

GenBank ID：JN247409

Promoter：CMV

Tag / Fusion Protein：human cytochrome C oxidase subunit VIII (N terminal on insert)

Bacterial Resistance(s)：Kanamycin

Selectable markers：Neomycin (select with G418)

Growth Temperature：37°C

Growth Strain(s)：DH5alpha

Copy number：High Copy

Other technical information

For more information, please download and refer to the product manual。
